Deutz-Allis 6275F
Deutz-Allis 6275F — Orchard/Vineyard tractor · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Weight
4850 to 5180 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-AllisReference
Orchard/Vineyard tractorReference
Two- or four-wheel driveReference
Power steeringReference
Hydraulic disc brakesReference
Two-post mid-mount folding ROPS. Cab optional.Reference
Variants
6275utilityReference
6275FnarrowReference
6275Llow-profileReference
Engine
Deutz 4.1L 4-cyl dieselReference
Fuel tank54.9 LReference
Deutz F4L913Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement4.1 LReference
Bore/Stroke100 x 123 mmReference
Pre-heatingthermo startReference
Rated RPM2350Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speedReference
12-speed creeperReference
16-speedReference
24-speedReference
Gears8 forward and 4 reverseReference
Clutch279mm dry discReference
TypecreeperReference
Gears12 forward and 4 reverseReference
TransmissionHi-LoReference
Gears16 forward and 8 reverseReference
TransmissionHi-Lo CreeperReference
Gears24 forward and 8 reverseReference
PTO & Hydraulics
PTO (claimed)52.9 kWReference
Typeopen centerReference
Pressure175.0 barReference
Valves1 to 4Reference
Pump flow70.0 lpmReference
Rear TypeIReference
Rear lift (at ends)2199 kgReference
Front lift1419 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase204 cmReference
Weight4850 to 5180 poundsReference
Front tire7.50x16Reference
2WD Rear tire14.9x28Reference
2WD Standard tires (ag)Front: 7.50x16. Rear: 14.9x28Reference
4WD Standard tires (ag)Front: 7.50x18. Rear: 14.9x28Reference
Width132 cmReference
2WD Weight2199 kgReference
4WD Weight2349 kgReference
Steering wheel132 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Battery volts12Reference
Battery AH110Reference
Deutz-Allis 6275F Height
ROPS204 cmReference
Cab215 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
