Tractor · 1985Unverified
Deutz-Allis 8070
Deutz-Allis 8070 — Row-Crop tractor · 171 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
171 hp
Max power
108.4 kW
Weight
16850 to 17300 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-AllisReference
Row-Crop tractorReference
Built in West Allis, Wisconsin, USAReference
Total built2,354Reference
Original price$60,337Reference
All 8000 series tractors were manufactured prior to the closure of the West Allis factory in 1985. Decal kits were provided to dealers for unsold inventory to replace the Allis Chalmers decals with Deutz-Allis.Reference
Two- or four-wheel driveReference
Differential lockelectro-hydraulic rearReference
Steeringhydrostatic powerReference
Differential hydraulic wet discs brakesReference
Acousta cab standard with heat and air-conditioning. Optional radio and cassette tape player.Reference
Engine
Allis Chalmers 7.0L 6-cyl dieselReference
Drawbar (tested)108.4 kWReference
Allis Chalmers 670IReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooled inlineReference
Displacement7.0 LReference
Bore/Stroke108 x 127 mmReference
Air cleanerdryReference
Compression15.5:1Reference
Rated RPM2400Reference
Starter volts12Reference
Oil capacity18.0 LReference
Oil capacity19.9 LReference
Coolant capacity34.1 LReference
Power at rated engine speed127.3 kWReference
Max power108.4 kWReference
Transmission
20-speed partial power shiftReference
12-speed Allis-ChalmersReference
TransmissionAllis-Chalmers Power DirectorReference
Typepartial power shiftReference
Gears20 forward and 4 reverseReference
Oil capacity28.0 LReference
Five gears (1-5) in two ranges (slow/fast) with a two-speed power shift (low/high) controlled by left-hand lever.Reference
TransmissionPower ShiftReference
TypeAllis-ChalmersReference
Gears12 forward and 2 reverseReference
Six power shift gears (1-6) in two ranges (slow/fast). Clutch must be used to shift range. Pressing the clutch pedal half-way automatically downshifts from 5th/6th to 4th gear.Reference
PTO & Hydraulics
PTO (tested)127.3 kWReference
Typeclosed-center load-sensitiveReference
Valves2 or 3Reference
Pump flow83.3 lpmReference
Pump flow51.1 lpmReference
Total flow170.3 lpmReference
Steering flow36.0 lpmReference
Rear TypeIII/IIReference
Rear lift (at 24"/610mm)3719 kgReference
Rear PTOindependentReference
Rear PTO Type1000Reference
Power at rated PTO speed127.8 kWReference
Capacities
Fuel227.1 LReference
Fuel94.6 LReference
Rear diff.64.7 LReference
Dimensions
Wheelbase269 cmReference
Weight16850 to 17300 poundsReference
Front tire10.00-16Reference
Rear tire18.4-38Reference
2WD Ag front10.00-16Reference
4WD Ag front13.6-28Reference
Ag rear18.4-38Reference
2WD Ag front11.00-16Reference
2WD Ag front14L-16Reference
2WD Ag front18.4-16Reference
4WD Ag front14.9-28Reference
4WD Ag front14.9-24Reference
Ag rear20.8-38Reference
Ag rear18.4-42Reference
Ag rear16.9-38Reference
Length474 cmReference
Width242 cmReference
Width303 cmReference
Clearance (front axle)55 cmReference
Clearance (rear axle)73 cmReference
Operating7643 kgReference
4WD Operating7847 kgReference
Ballasted10147 kgReference
8070 Serial Number Location
Serial number decal on the left side of the tractor's frame, just ahead of the fuel tank. Serial number also stamped into the casting at the rear of the tractor, above and to the left of the PTO shaft.Reference
8070 Serial Numbers
19811001Reference
19821004Reference
19831430Reference
19842090Reference
19852903Reference
Final3354Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemalternatorReference
Charging amps100Reference
Battery volts12Reference
Deutz-Allis 8070 Height
Hood177 cmReference
Cab294 cmReference
Exhaust289 cmReference
Test results
Diesel 12-speed 2WDSeptember 1 - 16, 1982Link: Nebraska Tractor Test 1449 fileReference
PTO performanceReference
Fuel use40.5 l/hourReference
Fuel use39.4 l/hourReference
Drawbar performanceReference
Gear 2F used for power test.Reference
Max pull8517 kgReference
Gear 2S used for pull test.Reference
Speeds
With 18.4x38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
