Tractor · 1989Unverified
Deutz-Allis 9170
Deutz-Allis 9170 — Row-Crop tractor · 173 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
173 hp
Max power
116.2 kW
Weight
15640 to 17465 pounds
Hover a source tag to verify
Overview
DistributorDeutz-AllisReference
ManufacturerWhiteReference
Row-Crop tractorReference
Built in Coldwater, Ohio, USAReference
Two- or four-wheel driveReference
Differential lockfront and rearReference
Power steeringReference
Differential hydraulic wet disc brakesReference
Engine
Deutz 9.6L 6-cyl dieselReference
Fuel tank340.7 LReference
Drawbar (tested)116.2 kWReference
Deutz BF6L513RReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement9.6 LReference
Bore/Stroke125 x 130 mmReference
Air cleanerdual paper elementsReference
Compression15.8:1Reference
Rated RPM2300Reference
Starter volts12Reference
Oil capacity23.0 LReference
Power at rated engine speed129.3 kWReference
Max power116.2 kWReference
Transmission
18-speed partial power shiftReference
Typepartial power shiftReference
Gears18 forward and 6 reverseReference
Clutch330mm discsReference
Six speeds with three-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)128.3 kWReference
PTO (tested)129.3 kWReference
Typeclosed centerReference
Pressure156.9 barReference
Valves2 or 3Reference
Pump flow87.1 lpmReference
Rear TypeIII/IIReference
Rear PTOindependentReference
Rear PTO Type1000 (1.75)Reference
Engine RPM1000@2168Reference
Power at rated PTO speed133.3 kWReference
Dimensions
2WD Wheelbase302 cmReference
4WD Wheelbase292 cmReference
Weight15640 to 17465 poundsReference
Front tire11.00-16Reference
2WD Rear tire18.4R38Reference
2WD Standard tires (ag)Front: 11.00-16. Rear: 18.4R38Reference
4WD Standard tires (ag)Front: 14.9R28. Rear: 18.4R38Reference
Width243 cmReference
Height309 cmReference
2WD Shipping7094 kgReference
4WD Shipping7275 kgReference
Operating7922 kgReference
Ballasted9743 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 18-speed 2WDOctober 31 - November 15, 1989Link: Nebraska Tractor Test 1634 fileReference
PTO performanceReference
Fuel use41.6 l/hourReference
Fuel use40.5 l/hourReference
Drawbar performanceReference
Fuel use42.0 l/hourReference
Gear 3D used for power test.Reference
Max pull8630 kgReference
Gear 2D used for pull test.Reference
Speeds
With 18.4R38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
