The Deutz D 3005 is a tractor with a rated output of 28 hp, classified as a compact option in its class. It was manufactured from 1965 to 1967. This tractor features a 2-cylinder diesel engine, coupled with a two-wheel drive system and an 8-speed gearbox. The listed weight of the Deutz D 3005 is 1635 kg, making it suitable for tasks involving up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
1635 kg
Catalogue coverage
Variants represented
2
Richest spec table
25 rows
Recorded power
28 hp
Recorded weight
1635 kg
Transmissions
8-speed
Production years
1965-1967
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Two-wheel driveReference
Open operator station.Reference
Engine
Deutz 1.7L 2-cyl dieselReference
Engine20.9 kWReference
DeutzReference
dieselReference
2-cylinderReference
Displacement1.7 LReference
Bore/Stroke95 x 120 mmReference
Power20.9 kWReference
Rated RPM2300Reference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Pump flow23.1 lpmReference
Rear lift1549 kgReference
Rear PTO Type540Reference
Dimensions
Wheelbase189 cmReference
Weight1635 kgReference
Front tire5.50-16Reference
Rear tire12.4-28Reference
Ag front5.50-16Reference
Ag rear12.4-28Reference
Length329 cmReference
Height159 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
