Tractor · 1967Unverified
Deutz D 3006
Deutz D 3006 — 06 Series · 30 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
30 hp
Weight
1868 kg
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Utility tractorReference
Two-wheel driveReference
Cab optional with heat.Reference
Engine
Deutz 1.9L 2-cyl dieselReference
Fuel tank70.0 LReference
Engine22.4 kWReference
Deutz F2L 912Reference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.9 LReference
Bore/Stroke100 x 120 mmReference
Power22.4 kWReference
Rated RPM2300Reference
Torque96.0 NmReference
Torque RPM1800Reference
Oil capacity3.9 LReference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Pump flow12.0 lpmReference
Rear PTOliveReference
Rear PTO Type540Reference
Dimensions
Wheelbase186 cmReference
Weight1868 kgReference
Front tire6.00-16Reference
Rear tire11-28Reference
Ag front6.00-16Reference
Ag rear11-28Reference
Ag rear9-32Reference
Length329 cmReference
Width160 cmReference
Height (steering wheel)152 cmReference
Height (ROPS)236 cmReference
Operating weight1868 kgReference
Max weight3089 kgReference
D 3006 Serial Number Location
Front-right of tractor frame, above front axle.Reference
Capacities
Diameter24 cmReference
Width9 cmReference
RPM1280Reference
Speed990.60 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
