Tractor · 1969Unverified
Deutz D 7006
Deutz D 7006 — 06 Series · 71 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
71 hp
Weight
5809 to 7033 pounds
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Utility tractorReference
Two- or four-wheel driveReference
SteeringmanualReference
SteeringpowerReference
Four-post ROPS optional. Cab optional with heater.Reference
Variants
D70062WDReference
D7006A4WDReference
Engine
Deutz 3.8L 4-cyl dieselReference
Fuel tank92.0 LReference
Engine (gross)52.9 kWReference
Engine (net)49.2 kWReference
Deutz F4L 912Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power (net)49.2 kWReference
Power (gross)52.9 kWReference
Rated RPM2300Reference
Transmission
9-speed partially synchronizedReference
8-speed synchromeshReference
12-speed synchromeshReference
Typepartially synchronizedReference
Gears9 forward and 3 reverseReference
The 9-speed was the early transmission, used until 1972.Reference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Pump flow27.3 lpmReference
Rear TypeIIReference
Rear lift2300 kgReference
Rear PTO Type540/1000 (1.375)Reference
Dimensions
Wheelbase240 cmReference
Weight5809 to 7033 poundsReference
Front tire7.50-16Reference
Rear tire16.9/14-34Reference
2WD Ag front7.50-16Reference
4WD Ag front12.5-20Reference
Ag rear16.9/14-34Reference
Length395 cmReference
Width195 cmReference
Height (steering wheel)186 cmReference
Height (ROPS)256 cmReference
2WD Operating weight2634 kgReference
4WD Operating weight3190 kgReference
2WD Front tread141 to 192 cmReference
4WD Front tread164 cmReference
Rear tread151 to 201 cmReference
Speeds
With 16.9/14-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
