Tractor · 1974Unverified
Deutz D 7206
Deutz D 7206 — 06 Series · 70 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
70 hp
Weight
6220 to 7340 pounds
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Two- or four-wheel driveReference
ROPS optional. EURO comfort cab optional with heater.Reference
Variants
D72062WDReference
D7206A4WDReference
Engine
Deutz 3.8L 4-cyl dieselReference
Fuel tank92.0 LReference
Engine52.2 kWReference
Deutz F4L 912Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power52.2 kWReference
Rated RPM2300Reference
Torque235.9 NmReference
Torque RPM1610Reference
Transmission
8-speed synchromeshReference
12-speed synchromesh with creeperReference
TransmissionDeutz TW 55.4Reference
TypesynchromeshReference
Gears8 forward and 4 reverseReference
Typesynchromesh with creeperReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow34.8 lpmReference
Rear lift2600 kgReference
Rear PTO Type540Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase241 cmReference
Weight6220 to 7340 poundsReference
Front tire7.50-18Reference
Rear tire13.6-38Reference
2WD Ag front7.50-18Reference
4WD Ag front9.5-24Reference
Ag rear13.6-38Reference
Length396 cmReference
Width195 cmReference
Height (steering wheel)180 cmReference
Height (ROPS)271 cmReference
2WD Operating2821 kgReference
4WD Operating3329 kgReference
Capacities
Max capacity4998 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
