Tractor · 1967Unverified
Deutz D 8006
Deutz D 8006 — 06 Series · 86 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
86 hp
Max power
51.8 kW
Weight
3214 kg
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Two- or four-wheel driveReference
Differential hydraulic shoe brakesReference
ROPS optional. Cab optional with heat.Reference
Variants
D80062WDReference
D8006A4WDReference
Engine
Deutz 5.7L 6-cyl dieselReference
Fuel tank92.0 LReference
Engine59.7 kWReference
Drawbar (tested)51.8 kWReference
Deutz F6L 912Reference
dieselReference
6-cylinderReference
air-cooledReference
Displacement5.7 LReference
Bore/Stroke100 x 120 mmReference
Power59.7 kWReference
Air cleanerdryReference
Compression17:1Reference
Rated RPM2100Reference
Starter volts12Reference
Power at rated engine speed63.8 kWReference
Max power51.8 kWReference
Transmission
16-speedReference
Gears16 forward and 7 reverseReference
PTO & Hydraulics
PTO (tested)63.8 kWReference
Typeopen centerReference
Pump flow34.8 lpmReference
Rear TypeIIReference
Rear lift (at ends)3600 kgReference
Rear PTOliveReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Rear PTO Type1000Reference
Power at rated PTO speed61.3 kWReference
Dimensions
Wheelbase255 cmReference
Weight3214 kgReference
Front tire7.50-20Reference
2WD Rear tire16.9-34Reference
2WD Standard tires (ag)Front: 7.50-20. Rear: 16.9-34Reference
4WD Standard tires (ag)Front: 12.5-20. Rear: 16.9-34Reference
2WD Length415 cmReference
4WD Length408 cmReference
Width199 cmReference
Height (ROPS)274 cmReference
Height (exhaust)275 cmReference
Operating weight3214 kgReference
Ballasted weight5016 kgReference
Ground clearance52 cmReference
Capacities
Diameter27 cmReference
Width17 cmReference
RPM1390Reference
Speed1219.20 meters/minReference
Test results
Diesel 16-speed 2WDAugust 17 - September 2, 1971Link: Nebraska Tractor Test 1074 fileReference
PTO performanceReference
Fuel use19.3 l/hourReference
Fuel use18.5 l/hourReference
Drawbar performanceReference
Fuel use18.9 l/hourReference
Gear 11 used for power test.Reference
Max pull4036 kgReference
Gear 8 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
