Tractor · 1950Unverified
Deutz F1L514 50
Deutz F1L514 50 — Model year 1950-19511951-1957 · 15 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
15 hp
Weight
1285 kg
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Built in GermanyReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Deutz 1.3L 1-cyl dieselReference
Fuel tank28.0 LReference
Engine11.0 kWReference
DeutzReference
dieselReference
1-cylinderReference
air-cooledReference
Displacement1.3 LReference
Bore/Stroke110 x 140 mmReference
Power11.0 kWReference
Rated RPM1650Reference
StarterelectricReference
Starter volts12Reference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase158 cmReference
Weight1285 kgReference
Front tire5.00-16Reference
Rear tire8.00-32Reference
Ag front5.00-16Reference
Ag rear8.00-32Reference
Ag rear10-28Reference
Length250 cmReference
Width160 cmReference
Height153 cmReference
Ground clearance40 cmReference
Rear tread124 to 150 cmReference
Capacities
Diameter22 cmReference
Width10 cmReference
RPM1100Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
