Tractor · 1954Unverified
Deutz F2L612 4
Deutz F2L612 4 — Model year 1954-19561956-1958 · 22 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1339 kg
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Built in GermanyReference
Two-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Engine
Deutz 1.5L 2-cyl dieselReference
Fuel tank29.9 LReference
Engine16.2 kWReference
DeutzReference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.5 LReference
Bore/Stroke90 x 120 mmReference
Power16.2 kWReference
Rated RPM2100Reference
StarterelectricReference
Starter volts12Reference
Transmission
10-speed gearReference
TransmissionDeutzReference
TypegearReference
Gears10 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase178 cmReference
Weight1339 kgReference
Front tire5.00-16Reference
Rear tire8-32Reference
Ag front5.00-16Reference
Ag rear8-32Reference
Ag rear10-28Reference
Length272 cmReference
Width160 cmReference
Height153 cmReference
Clearance (front axle)40 cmReference
Rear tread124 to 150 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
