Tractor · 1934Unverified
Deutz F2M315
Deutz F2M315 — FM Series · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
2300 kg
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Built in GermanyReference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Deutz 3.4L 2-cyl dieselReference
Fuel tank74.9 LReference
Engine20.6 kWReference
DeutzReference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement3.4 LReference
Power20.6 kWReference
Oil capacity12.0 LReference
Coolant capacity35.0 LReference
Transmission
4-speed gearReference
TypegearReference
Gears4 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase192 cmReference
Weight2300 kgReference
Front tire760x140Reference
Rear tire1100x270Reference
Ag front760x140 (steel)Reference
Ag rear1100x270 (steel)Reference
Length303 cmReference
Width150 cmReference
Height202 cmReference
Ground clearance28 cmReference
Front tread116/125 cmReference
Rear tread109 to 135 cmReference
Capacities
Diameter32 cmReference
Width18 cmReference
RPM800Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
