Tractor · 1956Unverified
Deutz F4L514 5
Deutz F4L514 5 — FL Series · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Weight
3025 kg
Hover a source tag to verify
Overview
ManufacturerDeutzReference
Built in GermanyReference
Two-wheel driveReference
Manual steeringReference
Drum brakesReference
Open operator station.Reference
Variants
F4L514/460 PSReference
F4L514/565 PSReference
Engine
Deutz 5.3L 4-cyl dieselReference
Engine47.8 kWReference
DeutzReference
dieselReference
4-cylinderReference
air-cooledReference
Displacement5.3 LReference
Bore/Stroke110 x 140 mmReference
Power47.8 kWReference
Rated RPM1800Reference
StarterelectricReference
Starter volts24Reference
Transmission
7-speed gearReference
TransmissionZFReference
TypegearReference
Gears7 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase244 cmReference
Weight3025 kgReference
Front tire6.50-20Reference
Rear tire13-30Reference
Ag front6.50-20Reference
Ag rear13-30Reference
Length389 cmReference
Width205 cmReference
Height199 cmReference
Clearance (front axle)46 cmReference
Rear tread154 to 180 cmReference
Capacities
Diameter34 cmReference
Width22 cmReference
RPM1275Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
