Tractor · 2018Unverified

Deutz-Fahr 4060E Keyline

Name: Deutz-Fahr 4060E Keyline
Brand: Deutz-Fahr

Deutz-Fahr 4060E Keyline — 4E Keyline Series · 59 hp. Reference specifications; pending source verification.

The Deutz-Fahr 4060E Keyline is a tractor with an engine rating of approximately 59 hp, positioned at the lower end of its class. It was manufactured in 2018. Equipped with a 3-cylinder turbocharged intercooled diesel engine, the tractor features a liquid cooling system and is paired with four-wheel drive and an 8-speed gearbox. Its listed operating weight ranges from 4630 to 5512 pounds, suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

59 hp

Weight

4630 to 5512 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

59 hp

Recorded weight

2100 kg

Transmissions

8-speed gear

Production years

2018-2018

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerDeutz-FahrReference

Utility tractorReference

Two- or four-wheel driveReference

Differential lockmechanicalReference

Power steeringReference

Open operator station. Two-post ROPS available.Reference

Engine

SDF 3.0L 3-cyl dieselReference

Fuel tank54.9 LReference

Engine44.1 kWReference

SDF 1000.3Reference

turbocharged intercooled dieselReference

3-cylinderReference

liquid-cooledReference

Displacement3.0 LReference

Bore/Stroke105 x 116 mmReference

EmissionsStage IIIAReference

Power44.1 kWReference

Rated RPM2200Reference

Torque221.0 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed gearReference

12-speed creeperReference

8-speed partially synchronizedReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutchmechanical dry discReference

TypecreeperReference

Gears12 forward and 3 reverseReference

Typepartially synchronizedReference

Gears8 forward and reverseReference

PTO & Hydraulics

Typeopen centerReference

Valves2 to 4Reference

Pump flow31.0 lpmReference

Rear TypeIIReference

Rear lift1599 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Rear PTO Type540/540EReference

Rear PTO Type540/1000Reference

Dimensions

2WD Wheelbase192 cmReference

4WD Wheelbase195 cmReference

Weight4630 to 5512 poundsReference

Length355 cmReference

Width180 cmReference

Height (steering wheel)163 cmReference

2WD ROPS Weight2100 kgReference

4WD ROPS Weight2500 kgReference

2WD Front tread146 cmReference

4WD Front tread148 cmReference

Rear tread144 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
