Tractor · 2018Unverified
Deutz-Fahr 4065E
Deutz-Fahr 4065E — 4E Series · 61 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
61 hp
Weight
5516 to 6504 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Utility tractorReference
Two- or four-wheel driveReference
Differential lockmechanicalReference
Power steeringReference
Wet disc brakesReference
Open operator station. Cab optional with available air-conditioning.Reference
Engine
SDF 3.0L 3-cyl dieselReference
Fuel tank70.0 LReference
Engine45.6 kWReference
SDF 1000.3 WTReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
Bore/Stroke105 x 116 mmReference
EmissionsStage IIIAReference
Power45.6 kWReference
Torque240.0 NmReference
StarterelectricReference
Starter volts12Reference
Transmission
30-speed partially synchronizedReference
Typepartially synchronizedReference
Gears30 forward and 15 reverseReference
Five synchronized gears in three ranges with shuttle and underdrive.Reference
PTO & Hydraulics
Typeopen centerReference
Valves2Reference
Pump flow42.0 lpmReference
Rear TypeIIReference
Rear lift2500 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Dimensions
2WD Wheelbase204 cmReference
4WD Wheelbase197 cmReference
Weight5516 to 6504 poundsReference
Width178 cmReference
2WD Open2502 kgReference
4WD Open2800 kgReference
2WD Cab2649 kgReference
4WD Cab2950 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Capacities
2WD Max capacity3800 kgReference
4WD Max capacity4799 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
