Tractor · 2013Unverified

Deutz-Fahr 5120

Name: Deutz-Fahr 5120
Brand: Deutz-Fahr

Deutz-Fahr 5120 — 5 Series · 111 hp. Reference specifications; pending source verification.

The Deutz-Fahr 5120 is a tractor model with a rated output of 111 horsepower, placing it in the middle of its class in terms of power. Manufactured from 2013 to 2017, this model is equipped with a 4-cylinder turbocharged intercooled diesel liquid-cooled engine, which drives the four-wheel drive system via a continuously variable transmission. The listed weight of the Deutz-Fahr 5120 falls within the range of 10957 to 11288 pounds, and it is designed to handle tasks covering around 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

111 hp

Weight

10957 to 11288 pounds

Catalogue coverage

Variants represented

Richest spec table

66 rows

Recorded power

111 hp

Transmissions

30-speed partial power shift

Production years

2013-2017

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerDeutz-FahrReference

Utility tractorReference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Cab standard with air-conditioning.Reference

Variants

5120TTVCVT transmissionReference

Engine

Deutz 3.6L 4-cyl dieselReference

Fuel tank202.9 LReference

Engine (gross)83.0 kWReference

Engine (max)87.0 kWReference

Deutz TCD 3.6 L04Reference

turbocharged intercooled dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.6 LReference

Bore/Stroke98 x 120 mmReference

Rated Power (gross)83.0 kWReference

Maximum Power (gross)87.0 kWReference

Fuel systemcommon railReference

Rated RPM2200Reference

Torque460.1 NmReference

Torque RPM1600Reference

StarterelectricReference

Starter volts12Reference

Oil capacity10.0 LReference

Oil change500 hReference

Transmission

30-speed partial power shiftReference

60-speed partial power shiftReference

infinitely variable transmissionReference

Typepartial power shiftReference

Gears30 forward and reverseReference

Five gears in two ranges with three-speed power shift and power shuttle.Reference

Gears60 forward and reverseReference

Five gears in four ranges with three-speed power shift and power shuttle.Reference

TransmissionZF TTVReference

Typeinfinitely variable transmissionReference

Gearsinfinite forward and reverseReference

PTO & Hydraulics

Pressure185.0 barReference

Pump flow60.0 lpmReference

Pump flow90.1 lpmReference

Rear TypeIIReference

Rear lift4650 kgReference

Rear lift6600 kgReference

Front lift1850 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540/540E/1000/1000EReference

Rear PTO Type540/540E/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

Wheelbase244 cmReference

Weight10957 to 11288 poundsReference

Front tire420/70R28Reference

Rear tire520/70R38Reference

Standard tires (ag)Front: 420/70R28. Rear: 520/70R38Reference

Length426 cmReference

Width228 cmReference

Height (cab)276 cmReference

Front tread164 to 215 cmReference

Rear tread174 to 205 cmReference

4970 kgReference

TTV5120 kgReference

Electrical

Charging systemalternatorReference

Battery volts12Reference

Capacities

Max capacity8500 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
