Tractor · 2014Unverified
Deutz-Fahr 6140.4 TTV
Deutz-Fahr 6140.4 TTV — 6 TTV Agrotron Series · 130 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
130 hp
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Row-Crop tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
MaxiVision Cab standard with air-conditioning.Reference
Engine
Deutz 4.0L 4-cyl dieselReference
Engine (gross)96.9 kWReference
Engine (max)107.4 kWReference
Deutz TCD 4.1 L04 4VReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.0 LReference
Bore/Stroke101 x 126 mmReference
Rated Power (gross)96.9 kWReference
Maximum Power (gross)107.4 kWReference
Fuel systemcommon railReference
Rated RPM2100Reference
StarterelectricReference
Starter volts12Reference
PTO & Hydraulics
Typeload sensingReference
Pump flow120.0 lpmReference
Rear lift6200 kgReference
Rear PTOindependentReference
Dimensions
Wheelbase241 cmReference
Length432 cmReference
Width255 cmReference
Height (cab)293 cmReference
Electrical
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
