The Deutz-Fahr Agrokid 230 is a tractor with a rated power output of 50 hp, situated at the lower end of its class in terms of power. It features a 4-cylinder turbocharged diesel liquid-cooled engine and a 12-speed gearbox paired with four-wheel drive. The operating weight of the model ranges from 2793 to 3411 pounds, and it is designed for use on plots of up to 200 acres. This model was built in 2007.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
2793 to 3411 pounds
Catalogue coverage
Variants represented
2
Richest spec table
50 rows
Recorded power
50 hp
Transmissions
12-speed shuttle
Production years
2007-2007
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Compact Utility tractorReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding mid-mount ROPS. Cab optional with available air-conditioning.Reference
Engine
Mitsubishi 1.8L 4-cyl dieselReference
Fuel tank37.9 LReference
Fuel tank53.0 LReference
Engine37.0 kWReference
MitsubishiReference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke78 x 92 mmReference
Power37.0 kWReference
Rated RPM3000Reference
Torque122.0 NmReference
Torque RPM2000Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed shuttleReference
16-speed creeperReference
TypeshuttleReference
Gears12 forward and reverseReference
TypecreeperReference
Gears16 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow29.9 lpmReference
Rear TypeIReference
Rear lift1200 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Rear PTO Type540/540EReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase174 cmReference
Weight2793 to 3411 poundsReference
Length297 cmReference
Width129 cmReference
Height (ROPS)201 cmReference
Height (cab)219 cmReference
Ground clearance39 cmReference
Front tread106 to 134 cmReference
Rear tread103 to 131 cmReference
ROPS1266 kgReference
ROPS1547 kgReference
Electrical
GroundnegativeReference
Battery volts12Reference
Capacities
Max capacity2299 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
