Tractor · 1997Unverified

Deutz-Fahr Agrokid 25

Name: Deutz-Fahr Agrokid 25
Brand: Deutz-Fahr

Deutz-Fahr Agrokid 25 — Agrokid Series · 25 hp. Reference specifications; pending source verification.

The Deutz-Fahr Agrokid 25 is a tractor with a rating of approximately 25 hp, situated at the lower end of its class in terms of power output. In production from 1997 to 2002, the Agrokid 25 features a 3-cylinder diesel liquid-cooled engine coupled with four-wheel drive and a hydrostatic transmission. Its operating weight is specified at 1005 kg, and it is suitable for use on areas of up to 200 acres. The tractor's dimensions and performance capabilities are detailed in the following specifications.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1005 kg

Catalogue coverage

Variants represented

Richest spec table

44 rows

Recorded power

25 hp

Recorded weight

1005 kg

Transmissions

12-speed shuttle

Production years

1997-2002

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerDeutz-FahrReference

Compact Utility tractorReference

Four-wheel driveReference

Mechanical wet disc brakesReference

Two-post mid-mount folding ROPS. Cab optional.Reference

Engine

Mitsubishi 1.1L 3-cyl dieselReference

Fuel tank29.1 LReference

Engine18.5 kWReference

Mitsubishi K3FReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.1 LReference

Power18.5 kWReference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed shuttleReference

hydrostaticReference

TypeshuttleReference

Gears12 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Typeopen centerReference

Pump flow22.0 lpmReference

Rear TypeIReference

Rear lift1200 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Dimensions

Wheelbase153 cmReference

Weight1005 kgReference

Front tire650-12Reference

Rear tire250/80-18Reference

Standard tires (ag)Front: 650-12. Rear: 250/80-18Reference

Length268 cmReference

Width108 cmReference

Max weight2100 kgReference

Ground clearance28 cmReference

Front tread82 to 103 cmReference

Rear tread81 to 101 cmReference

Steering wheel113 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Deutz-Fahr Agrokid 25 Height

ROPS196 cmReference

Cab202 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
