Tractor · 2005Unverified
Deutz-Fahr Agrotron 150.7
Deutz-Fahr Agrotron 150.7 — Agrotron Series · 164 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
164 hp
Weight
5880 kg
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 7.1L 6-cyl dieselReference
Fuel tank305.1 LReference
Engine (gross)122.0 kWReference
Deutz BF6M1013ECReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.1 LReference
Bore/Stroke108 x 130 mmReference
Rated Power (gross)122.0 kWReference
Rated RPM2350Reference
Torque588.1 NmReference
Torque RPM1600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity21.0 LReference
Transmission
24-speed four-speed power shiftReference
40-speed creeperReference
Typefour-speed power shiftReference
Gears24 forward and reverseReference
TypecreeperReference
Gears40 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Typeclosed centerReference
Pressure200.0 barReference
Valves2 to 4Reference
Pump flow82.9 lpmReference
Pump flow120.0 lpmReference
Rear TypeIII/IIReference
Rear lift9200 kgReference
Front HitchIIReference
Front lift3999 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM540E@1600Reference
Engine RPM1000@2200Reference
Engine RPM1000E@1600Reference
Front PTOindependentReference
Clutch1000:2130Reference
Front PTO Type1000Reference
Dimensions
Wheelbase276 cmReference
Weight5880 kgReference
Front tire16.9R28Reference
Rear tire20.8R38Reference
Standard tires (ag)Front: 16.9R28. Rear: 20.8R38Reference
Length475 cmReference
Height (cab)299 cmReference
Max weight9500 kgReference
Front tread189 cmReference
Rear tread189 cmReference
Electrical
Charging systemalternatorReference
Charging amps95Reference
Battery volts12Reference
Battery AH143Reference
Battery AH170Reference
Speeds
With 20.8R38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
