Tractor · 2005Unverified
Deutz-Fahr Agrotron 180.7
Deutz-Fahr Agrotron 180.7 — Agrotron Series · 180 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
180 hp
Weight
6750 kg
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 7.1L 6-cyl dieselReference
Fuel tank305.1 LReference
Engine (gross)134.0 kWReference
Deutz BF6M1013ECReference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.1 LReference
Bore/Stroke108 x 130 mmReference
Rated Power (gross)134.0 kWReference
Rated RPM2350Reference
Torque775.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity21.0 LReference
Transmission
24-speed four-speed power shiftReference
40-speed creeperReference
Typefour-speed power shiftReference
Gears24 forward and reverseReference
TypecreeperReference
Gears40 forward and reverseReference
PTO & Hydraulics
Typeclosed centerReference
Pressure200.0 barReference
Valves2 to 4Reference
Pump flow120.0 lpmReference
Rear TypeIII/IIReference
Rear lift9200 kgReference
Front HitchIIReference
Front lift3999 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2200Reference
Engine RPM540E@1600Reference
Engine RPM1000@2200Reference
Engine RPM1000E@1600Reference
Front PTOindependentReference
Clutch1000:2130Reference
Front PTO Type1000Reference
Dimensions
Wheelbase281 cmReference
Weight6750 kgReference
Front tire540/65R34Reference
Rear tire650/65R42Reference
Standard tires (ag)Front: 540/65R34. Rear: 650/65R42Reference
Length480 cmReference
Height (cab)312 cmReference
Max weight11013 kgReference
Front tread187 cmReference
Rear tread186 cmReference
Electrical
Charging systemalternatorReference
Charging amps95Reference
Battery volts12Reference
Battery AH143Reference
Battery AH170Reference
Speeds
With 650/65R42 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
