Tractor · 2010Unverified
Deutz-Fahr Argotron L 710
Deutz-Fahr Argotron L 710 — Agrotron L Series · 186 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
186 hp
Weight
8218 kg
Hover a source tag to verify
Overview
ManufacturerDeutz-Fahr (a part of SAME)Reference
Row-Crop tractorReference
Four-wheel driveReference
Differential lockeletro-hydraulic front and rearReference
Power steeringReference
Wet disc brakesReference
Trailer brakeshydraulicReference
Cab standard with air-conditioning.Reference
Engine
Deutz 7.1L 6-cyl dieselReference
Fuel tank380.0 LReference
Engine (gross)139.0 kWReference
Engine (max)145.0 kWReference
Deutz TCD 2013 L06Reference
turbocharged intercooled dieselReference
6-cylinderReference
liquid-cooledReference
Displacement7.1 LReference
Bore/Stroke108 x 130 mmReference
Rated Power (gross)139.0 kWReference
Maximum Power (gross)145.0 kWReference
Rated RPM2350Reference
Idle RPM850-2350Reference
Torque793.1 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
24-speed 12-speed power shiftReference
33-speed creeperReference
Type12-speed power shiftReference
Gears24 forward and reverseReference
Twelve power shift gears in two ranges with power shuttle.Reference
TypecreeperReference
Gears33 forward and reverseReference
Additional nine-speed creeper range added to the standard transmission.Reference
PTO & Hydraulics
Pressure180.0 barReference
Rear valves5Reference
Front valves2Reference
Pump flow113.2 lpmReference
Steering flow37.1 lpmReference
Rear lift10000 kgReference
Front lift3999 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulic wet discReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1650Reference
Engine RPM1000@2136Reference
Front PTOindependentReference
Front PTO Type1000 (1.375)Reference
Engine RPM1000@2043Reference
Dimensions
Wheelbase298 cmReference
Weight8218 kgReference
Front tire540/65R34Reference
Rear tire650/65R42Reference
Standard tires (ag)Front: 540/65R34. Rear: 650/65R42Reference
Length500 cmReference
Width249 cmReference
Height303 cmReference
Max weight11900 kgReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
