Deutz-Fahr D 5207
Deutz-Fahr D 5207 — 07 Series · 51 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
51 hp
Weight
5952 to 6592 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Utility tractorReference
Two- or four-wheel driveReference
Power steeringReference
Mechanical disc brakesReference
Four-post ROPS. Cab available with heat.Reference
Engine
Deutz 2.8L 3-cyl dieselReference
Fuel tank70.0 LReference
Engine38.0 kWReference
Deutz F3L 912Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 120 mmReference
Power38.0 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed synchronizedReference
TransmissionTW50.31Reference
TypesynchronizedReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure175.0 barReference
Pump flow34.8 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift2404 kgReference
Front HitchIReference
Front lift1529 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
2WD Wheelbase200 cmReference
4WD Wheelbase205 cmReference
Weight5952 to 6592 poundsReference
Front tire7.50-16Reference
2WD Rear tire14.9-28Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 14.9-28Reference
4WD Standard tires (ag)Front: 10.5-18. Rear: 14.9-28Reference
2WD Length348 cmReference
4WD Length357 cmReference
Width209 cmReference
Height243 cmReference
2WD Ground clearance45 cmReference
4WD Ground clearance29 cmReference
2WD Front tread135 to 184 cmReference
Rear tread139 to 189 cmReference
2WD Operating2699 kgReference
4WD Operating2990 kgReference
Capacities
Max capacity3999 kgReference
Speeds
With 14.9-28 rear tires.Reference
