Tractor · 1980Unverified

Deutz-Fahr D 5207

Name: Deutz-Fahr D 5207
Brand: Deutz-Fahr

Deutz-Fahr D 5207 — 07 Series · 51 hp. Reference specifications; pending source verification.

The Deutz-Fahr D 5207 is a tractor model rated at 51 hp — making it one of the more compact options in its class. It was manufactured from 1980 to 1984. Under the hood is a 3-cylinder diesel air-cooled engine, driving through four-wheel drive with a 8-speed gearbox. Listed weight is 5952 to 6592 pounds, and it is aimed at jobs of around up to 200 ac. Available dimensions and performance figures follow in both unit systems.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

51 hp

Weight

5952 to 6592 pounds

Catalogue coverage

Variants represented

Richest spec table

54 rows

Recorded power

51 hp

Transmissions

8-speed synchronized

Production years

1980-1984

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerDeutz-FahrReference

Utility tractorReference

Two- or four-wheel driveReference

Power steeringReference

Mechanical disc brakesReference

Four-post ROPS. Cab available with heat.Reference

Engine

Deutz 2.8L 3-cyl dieselReference

Fuel tank70.0 LReference

Engine38.0 kWReference

Deutz F3L 912Reference

dieselReference

3-cylinderReference

air-cooledReference

Displacement2.8 LReference

Bore/Stroke100 x 120 mmReference

Power38.0 kWReference

Rated RPM2300Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed synchronizedReference

TransmissionTW50.31Reference

TypesynchronizedReference

Gears8 forward and 4 reverseReference

PTO & Hydraulics

Typeopen centerReference

Pressure175.0 barReference

Pump flow34.8 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift2404 kgReference

Front HitchIReference

Front lift1529 kgReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Front PTOindependentReference

Front PTO Type1000Reference

Dimensions

2WD Wheelbase200 cmReference

4WD Wheelbase205 cmReference

Weight5952 to 6592 poundsReference

Front tire7.50-16Reference

2WD Rear tire14.9-28Reference

2WD Standard tires (ag)Front: 7.50-16. Rear: 14.9-28Reference

4WD Standard tires (ag)Front: 10.5-18. Rear: 14.9-28Reference

2WD Length348 cmReference

4WD Length357 cmReference

Width209 cmReference

Height243 cmReference

2WD Ground clearance45 cmReference

4WD Ground clearance29 cmReference

2WD Front tread135 to 184 cmReference

Rear tread139 to 189 cmReference

2WD Operating2699 kgReference

4WD Operating2990 kgReference

Capacities

Max capacity3999 kgReference

Speeds

With 14.9-28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
