Tractor · 1981Unverified
Deutz-Fahr DX 130
Deutz-Fahr DX 130 — DX Series · 121 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
121 hp
Max power
76.5 kW
Weight
6323 kg
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Differential lockhydraulic foot-operatedReference
Steeringhydrostatic powerReference
Hydraulic disc brakesReference
Cab standard with air-conditioning.Reference
Engine
Deutz 6.1L 6-cyl dieselReference
Fuel tank151.4 LReference
Fuel tank249.8 LReference
Drawbar (tested)76.5 kWReference
Deutz BF6L 913Reference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement6.1 LReference
Bore/Stroke102 x 125 mmReference
Compression15.5:1Reference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity16.0 LReference
Power at rated engine speed90.4 kWReference
Max power76.5 kWReference
Transmission
24-speed two-speed power shiftReference
Typetwo-speed power shiftReference
Gears24 forward and 8 reverseReference
Clutchhydraulic dry discReference
Oil capacity53.0 LReference
Four gears (1-4) in three ranges (low, medium, high) with two-speed power shift.Reference
PTO & Hydraulics
PTO (claimed)89.5 kWReference
PTO (tested)90.4 kWReference
Typeopen centerReference
Valves1 to 3Reference
Total flow102.2 lpmReference
Rear TypeIII/IIReference
Rear lift (at ends)6500 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2070Reference
Engine RPM1000@2070Reference
Power at rated PTO speed90.5 kWReference
Dimensions
Wheelbase275 cmReference
Weight6323 kgReference
Front tire11.00-16Reference
Rear tire18.4-38 (2WD)Reference
Standard tires (ag)Front: 11.00-16. Rear: 18.4-38 (2WD)Reference
Standard tires (ag)Front: 14.9-28. Rear: 20.8-38 (4WD)Reference
Width236 cmReference
Height287 cmReference
Operating weight6323 kgReference
Ballasted weight7996 kgReference
Rear tread160 to 218 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Test results
Diesel 24-speed 2WDSeptember 12 - 22, 1981Link: Nebraska Tractor Test 1404 fileReference
PTO performanceReference
Fuel use27.6 l/hourReference
Fuel use26.1 l/hourReference
Drawbar performanceReference
Gear 3MH used for power test.Reference
Max pull6534 kgReference
Gear 1ML used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
