Tractor · 1978Unverified

Deutz-Fahr DX 140

Deutz-Fahr DX 140 — DX Series · 131 hp. Reference specifications; pending source verification.

The Deutz-Fahr DX 140 is a tractor model with a power rating of approximately 131 horsepower, placing it at the more powerful end of its class. It was produced from 1978 to 1983 and is equipped with a 6-cylinder turbocharged diesel, air-cooled engine, paired with a four-wheel drive system and a 24-speed gearbox. Its operating weight is listed as between 12171 and 13185 pounds. The tractor is suitable for operations on land areas of between 200 and 800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
131 hp
Weight
12171 to 13185 pounds

Catalogue coverage

Variants represented
2
Richest spec table
46 rows
Recorded power
131 hp
Recorded weight
5520 kg
Transmissions
24-speed
Production years
1978-1983
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerDeutz-FahrReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Hydraulic wet disc brakesReference
Cab standard with air-conditioning.Reference

Engine

Deutz 6.1L 6-cyl dieselReference
Fuel tank149.9 LReference
Deutz F6LReference
turbocharged dieselReference
6-cylinderReference
air-cooledReference
Displacement6.1 LReference
Bore/Stroke102 x 125 mmReference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity16.0 LReference

Transmission

24-speedReference
Gears24 forward and 8 reverseReference
Clutch350mm wet discReference
Oil capacity55.0 LReference

PTO & Hydraulics

PTO (claimed)97.7 kWReference
Typeopen centerReference
Pressure171.3 barReference
Pump flow68.1 lpmReference
Rear TypeIII/IIReference
Rear lift (at ends)5407 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type1000 (1.75)Reference
Rear PTO Type540/1000Reference

Dimensions

Wheelbase283 cmReference
Weight12171 to 13185 poundsReference
Front tire11.00-16Reference
Rear tire18.4-38Reference
Ag front11.00-16Reference
Ag front13.6-28 (4WD)Reference
Ag rear18.4-38Reference
Length471 cmReference
Height273 cmReference
2WD Weight5520 kgReference
4WD Weight5980 kgReference
Rear tread160 to 220 cmReference

Electrical

GroundnegativeReference
Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
