Tractor · 1985Unverified
Deutz-Fahr DX 4.10
Deutz-Fahr DX 4.10 — DX4 Series · 68 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
68 hp
Weight
3920 kg
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Utility tractorReference
Four-wheel driveReference
Power steeringReference
Hydraulic drum brakesReference
Engine
Deutz 3.8L 4-cyl dieselReference
Fuel tank120.0 LReference
Engine51.0 kWReference
Deutz F4L 912Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power51.0 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
15-speed synchronizedReference
20-speed creeperReference
TypesynchronizedReference
Gears15 forward and 5 reverseReference
Five gears (1-5) in three ranges (L/M/H) plus reverse (R) range.Reference
TypecreeperReference
Gears20 forward and 5 reverseReference
PTO & Hydraulics
Pump flow40.1 lpmReference
Rear TypeIIReference
Rear lift3803 kgReference
Front HitchIIReference
Front lift1799 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Front PTOindependentReference
Front PTO Type1000Reference
Dimensions
Wheelbase240 cmReference
Weight3920 kgReference
Front tire13.6-24Reference
Rear tire18.4-34Reference
Standard tires (ag)Front: 13.6-24. Rear: 18.4-34Reference
Length414 cmReference
Width230 cmReference
Height268 cmReference
Max weight5699 kgReference
Ground clearance42 cmReference
Front tread150 to 189 cmReference
Rear tread160 to 199 cmReference
Speeds
With 18.4-34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
