Tractor · 1983Unverified
Deutz-Fahr DX 6.10
Deutz-Fahr DX 6.10 — DX6 Series · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
4710 kg
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Row-Crop tractorReference
Four-wheel driveReference
Engine
Deutz 5.7L 6-cyl dieselReference
Fuel tank120.0 LReference
Engine74.6 kWReference
Deutz F6L 912Reference
dieselReference
6-cylinderReference
air-cooledReference
Displacement5.7 LReference
Bore/Stroke100 x 120 mmReference
Power74.6 kWReference
Rated RPM2300Reference
Starter volts12Reference
Transmission
20-speedReference
TransmissionTW 904Reference
Gears20 forward and 5 reverseReference
Five gears (1-5) in four ranges (LL/L/M/H) plus reverse (R) range.Reference
PTO & Hydraulics
Pump flow56.0 lpmReference
Rear lift5200 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase270 cmReference
Weight4710 kgReference
Front tire13.6R24Reference
Rear tire16.9R38Reference
Ag front13.6R24Reference
Ag rear16.9R38Reference
Length454 cmReference
Height274 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Speeds
With 18.4-38 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
