Tractor · 1978Unverified
Deutz-Fahr DX 90
Deutz-Fahr DX 90 — DX Series · 84 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
84 hp
Weight
9856 to 10650 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Row-Crop tractorReference
Two- or four-wheel driveReference
Final drivesbull gearReference
Power steeringReference
Hydraulic dry disc brakesReference
Cab standard with air-conditioning.Reference
Variants
DX 902WDReference
DX 90A4WDReference
Engine
Deutz 4.7L 5-cyl dieselReference
Deutz F5L 912Reference
dieselReference
5-cylinderReference
air-cooledReference
Displacement4.7 LReference
Bore/Stroke100 x 120 mmReference
Rated RPM2300Reference
Oil capacity13.0 LReference
Transmission
15-speed fully synchronizedReference
Typefully synchronizedReference
Gears15 forward and 5 reverseReference
Clutchdry discReference
Oil capacity48.0 LReference
Five gears (1-5) in three ranges (low, medium, high).Reference
PTO & Hydraulics
PTO (claimed)62.6 kWReference
Hydraulic system15.0 LReference
Typeopen centerReference
Capacity15.0 LReference
Pump flow39.4 lpmReference
Rear TypeIIReference
Rear lift3501 kgReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel120.0 LReference
Dimensions
Wheelbase256 cmReference
Weight9856 to 10650 poundsReference
Front tire10.00-16Reference
2WD Rear tire18.4x34Reference
2WD Standard tires (ag)Front: 10.00-16. Rear: 18.4x34Reference
4WD Standard tires (ag)Front: 13.6-24. Rear: 18.4x34Reference
Length432 cmReference
Height260 cmReference
2WD Weight4470 kgReference
4WD Weight4830 kgReference
Rear tread149 to 200 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
