Tractor · 1972Unverified
Deutz-Fahr Intrac 2002
Deutz-Fahr Intrac 2002 — Intrac 2000 Series · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
5372 to 6724 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Tool Carrier tractorReference
Two- or four-wheel driveReference
2WD SteeringmanualReference
4WD SteeringpowerReference
Variants
2002A4WDReference
Engine
Deutz 2.8L 3-cyl dieselReference
Engine37.5 kWReference
Deutz F3L912Reference
dieselReference
3-cylinderReference
air-cooledReference
Displacement2.8 LReference
Bore/Stroke100 x 120 mmReference
Power37.5 kWReference
Rated RPM2300Reference
Transmission
8-speed synchronizedReference
12-speed creeperReference
TypesynchronizedReference
Gears8 forward and 4 reverseReference
Four gears in two ranges, plus reverse range.Reference
TypecreeperReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Pump flow27.3 lpmReference
Rear TypeII/IReference
Rear lift2236 kgReference
Front HitchIReference
Front lift1169 kgReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM2100Reference
Front PTO Type1000 (1.375)Reference
Dimensions
2WD Wheelbase215 cmReference
4WD Wheelbase219 cmReference
Weight5372 to 6724 poundsReference
Front tire7.50-16Reference
2WD Rear tire12.4/11-32Reference
2WD Standard tires (ag)Front: 7.50-16. Rear: 12.4/11-32Reference
4WD Standard tires (ag)Front: 7.50-18. Rear: 12.4/11-32Reference
Length424 cmReference
Width188 cmReference
Height (cab)249 cmReference
2WD Weight2436 kgReference
4WD Weight3050 kgReference
2WD Ground clearance45 cmReference
4WD Ground clearance25 cmReference
2WD Front tread153 to 183 cmReference
Front tread153 cmReference
Rear tread151 to 182 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
