Tractor · 1974Unverified
Deutz-Fahr Intrac 2003
Deutz-Fahr Intrac 2003 — Intrac 2000 Series · 59 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
59 hp
Weight
6240 to 7606 pounds
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Tool Carrier tractorReference
Two- or four-wheel driveReference
2WD SteeringmanualReference
4WD SteeringpowerReference
Cab standard.Reference
Engine
Deutz 3.8L 4-cyl dieselReference
Fuel tank87.1 LReference
Engine44.0 kWReference
Deutz F4L912Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement3.8 LReference
Bore/Stroke100 x 120 mmReference
Power44.0 kWReference
Rated RPM2050Reference
Transmission
8-speedReference
8-speed synchronizedReference
12-speed creeperReference
Gears8 forward and 2 reverseReference
TypesynchronizedReference
Gears8 forward and 4 reverseReference
Four gears in two ranges, plus reverse range. Optional high-speed road gear.Reference
TypecreeperReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Pump flow39.7 lpmReference
Rear TypeII/IReference
Rear lift2399 kgReference
Front HitchIReference
Front lift1000 kgReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@1890Reference
Engine RPM1000@1875Reference
Front PTO Type1000 (1.375)Reference
Dimensions
4WD Wheelbase219 cmReference
Weight6240 to 7606 poundsReference
Front tire7.50-18Reference
4WD Rear tire12.4-32Reference
4WD Standard tires (ag)Front: 7.50-18. Rear: 12.4-32Reference
Length429 cmReference
Width188 cmReference
Height (cab)249 cmReference
2WD Weight2830 kgReference
4WD Weight3450 kgReference
Ground clearance30 cmReference
Front tread153 cmReference
Rear tread151 to 182 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
