Tractor · 1974Unverified

Deutz-Fahr Intrac 2005

Name: Deutz-Fahr Intrac 2005
Brand: Deutz-Fahr

Deutz-Fahr Intrac 2005 — Intrac 2000 Series · 85 hp. Reference specifications; pending source verification.

The Deutz-Fahr Intrac 2005 is a tractor model with an 85 hp rated output, positioning it in the middle of its class for power. It was manufactured from 1974 to 1975. The tractor features a 5-cylinder diesel air-cooled engine, which drives a four-wheel drive system with a hydrostatic transmission. Its listed weight is 2500 kg, and it is suited for tasks involving up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

85 hp

Weight

2500 kg

Catalogue coverage

Variants represented

Richest spec table

50 rows

Recorded power

85 hp

Recorded weight

2500 kg

Transmissions

hydrostatic

Production years

1974-1975

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerDeutz-FahrReference

Tool Carrier tractorReference

Drive4x4 4WDReference

Power steeringReference

Drum brakesReference

Cab standard.Reference

Engine

Deutz 4.7L 5-cyl dieselReference

Fuel tank140.0 LReference

Engine (gross)63.2 kWReference

Deutz F5L912Reference

dieselReference

5-cylinderReference

air-cooledReference

Displacement4.7 LReference

Bore/Stroke100 x 120 mmReference

Power (gross)63.2 kWReference

Rated RPM2500Reference

Transmission

hydrostaticReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

PTO & Hydraulics

Rear TypeIIReference

Rear lift3200 kgReference

Front HitchIReference

Front lift1599 kgReference

Rear PTO Type540/1000 (1.375)Reference

Engine RPM540@2300Reference

Engine RPM1000@2300Reference

Front PTO Type1000 (1.375)Reference

Dimensions

Wheelbase249 cmReference

Weight2500 kgReference

Front tire12.5-20Reference

Rear tire12.5-20Reference

Ag front12.5-20Reference

Ag rear12.5-20Reference

Ag front9.5/9-30Reference

Ag front11.2/10-28Reference

Ag front13/11.25-24Reference

Ag front14.9/80-24Reference

Ag front14.5-20Reference

Ag front14.5-24Reference

Ag rear9.5/9-30Reference

Ag rear11.2/10-28Reference

Ag rear13/11.25-24Reference

Ag rear14.9/80-24Reference

Ag rear14.5-20Reference

Ag rear14.5-24Reference

Length439 cmReference

Width219 cmReference

Height (cab)252 cmReference

Ground clearance50 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
