The Deutz-Fahr Intrac 6.30 is a tractor with a rating of approximately 126 horsepower, positioning it at the higher end of its class. This model was manufactured between 1987 and 1989. It features a 6-cylinder diesel air-cooled engine and four-wheel drive, paired with a 15-speed gearbox, and has an operating weight of 6230 kg. The tractor is suitable for operations spanning 200-800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
126 hp
Weight
6230 kg
Catalogue coverage
Variants represented
2
Richest spec table
36 rows
Recorded power
126 hp
Recorded weight
6230 kg
Transmissions
15-speed
Production years
1987-1989
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerDeutz-FahrReference
Tool Carrier tractorReference
Drive4x4 4WDReference
Engine
Deutz 6.1L 6-cyl dieselReference
Fuel tank249.8 LReference
Engine94.0 kWReference
Deutz F6L913Reference
dieselReference
6-cylinderReference
air-cooledReference
Displacement6.1 LReference
Bore/Stroke102 x 125 mmReference
Power94.0 kWReference
Rated RPM2400Reference
Torque383.7 NmReference
Torque RPM1600Reference
Transmission
15-speedReference
30-speedReference
Gears15 forward and 5 reverseReference
Gears30 forward and 10 reverseReference
PTO & Hydraulics
Pressure175.0 barReference
Pump flow58.7 lpmReference
Rear lift4450 kgReference
Rear PTO Type540/1000Reference
Front PTO Type1000Reference
Dimensions
Wheelbase270 cmReference
Weight6230 kgReference
Front tire18.4R30Reference
Rear tire18.4R30Reference
Ag front18.4R30Reference
Ag rear18.4R30Reference
Length518 cmReference
Width239 cmReference
Height312 cmReference
Max weight9300 kgReference
Ground clearance53 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
