Tractor · Unverified
Dongfeng DF-204
Dongfeng DF-204 · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1090 kg
Hover a source tag to verify
Overview
ManufacturerDongfengReference
Built in Changzhou, Jiangsu, ChinaReference
Four-wheel driveReference
Steeringhydraulic powerReference
Disc brakesReference
Variants
DF-2002WDReference
Engine
1.4L 3-cyl dieselReference
Engine18.3 kWReference
Y380TReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.4 LReference
Bore/Stroke80 x 90 mmReference
Power18.3 kWReference
Rated RPM2600Reference
Transmission
8-speedReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear TypeIReference
Rear lift (at 24"/610mm)423 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/730Reference
Dimensions
Wheelbase152 cmReference
Weight1090 kgReference
Front tire6.00-12Reference
Rear tire8.3-24Reference
Ag front6.00-12Reference
Ag rear8.3-24Reference
Length266 cmReference
Width115 cmReference
Height136 cmReference
Ground clearance29 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
