Tractor · Unverified
Dongfeng DF-504
Dongfeng DF-504 · 50 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
1840 kg
Hover a source tag to verify
Overview
ManufacturerDongfengReference
Built in Changzhou, Jiangsu, ChinaReference
Four-wheel driveReference
Steeringhydraulic powerReference
Wet disc brakesReference
Variants
DF-5002WDReference
Engine
3.3L 4-cyl dieselReference
Engine37.3 kWReference
JD4100TReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.3 LReference
Bore/Stroke95 x 105 mmReference
Power37.3 kWReference
Rated RPM2400Reference
Transmission
12-speedReference
Gears12 forward and 3 reverseReference
PTO & Hydraulics
Rear TypeIIReference
Rear lift (at 24"/610mm)900 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase190 cmReference
Weight1840 kgReference
Front tire7.50-16Reference
Rear tire12.4-28Reference
Ag front7.50-16Reference
Ag rear12.4-28Reference
Length372 cmReference
Width161 cmReference
Height216 cmReference
Ground clearance36 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
