Tractor · 1913Unverified

Eagle Manufacturing D 12-22

Name: Eagle Manufacturing D 12-22
Brand: Eagle Manufacturing

Eagle Manufacturing D 12-22 — Standard-tread tractor · 12 hp. Reference specifications; pending source verification.

The Eagle Manufacturing D 12-22 is a tractor with a rated power output of 12 hp, positioning it at the lighter end of its class. This model was manufactured from 1913 to 1916 and features a 2-cylinder liquid-cooled engine, coupled with two-wheel drive. Its operating weight is listed as 2358 kg. The D 12-22 is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

12 hp

Weight

2358 kg

Catalogue coverage

Variants represented

Richest spec table

29 rows

Recorded power

12 hp

Recorded weight

2358 kg

Transmissions

gear

Production years

1913-1916

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerEagle ManufacturingReference

Standard-tread tractorReference

Built in Appleton, Wisconsin, USAReference

Two-wheel driveReference

SteeringmanualReference

Open operator station.Reference

Engine

Eagle Manufacturing 10.1L 2-cyl keroseneReference

Fuel tank75.7 LReference

Drawbar (claimed)8.9 kWReference

Belt (claimed)16.4 kWReference

Eagle ManufacturingReference

keroseneReference

2-cylinder 4-valveReference

liquid-cooledReference

Displacement10.1 LReference

Bore/Stroke178 x 203 mmReference

Rated RPM400Reference

Starter typehand-crankReference

Coolant capacity30.3 LReference

Transmission

gearReference

TypegearReference

Dimensions

Weight2358 kgReference

Rear tire44x12Reference

Ag rear44x12 (steel)Reference

Length304 cmReference

Width177 cmReference

Height152 cmReference

Capacities

Diameter50 cmReference

Width22 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
