Tractor · Unverified
Eagle Manufacturing E 20-35
Eagle Manufacturing E 20-35 — ???? - 1930 Standard-tread tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
3402 kg
Hover a source tag to verify
Overview
ManufacturerEagle ManufacturingReference
Standard-tread tractorReference
Built in Appleton, Wisconsin, USAReference
Two-wheel driveReference
Final drivesspur gearReference
SteeringmanualReference
Open operator station.Reference
Engine
Eagle Manufacturing 14.9L 2-cyl keroseneReference
Drawbar (claimed)14.9 kWReference
Belt (claimed)26.1 kWReference
Plows3-4 (14-inch)Reference
Eagle ManufacturingReference
keroseneReference
2-cylinder 4-valveReference
liquid-cooledReference
Displacement14.9 LReference
Bore/Stroke203 x 229 mmReference
Fuel systemSchebler carburetorReference
Rated RPM450Reference
Starter typehand-crankReference
Transmission
2-speed gearReference
TypegearReference
Gears2 forward and 1 reverseReference
Dimensions
Weight3402 kgReference
Rear tire48x14Reference
Ag rear48x14 (steel)Reference
Length353 cmReference
Width185 cmReference
Height182 cmReference
Capacities
Diameter60 cmReference
Width25 cmReference
RPM450Reference
Speed853.44 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
