Tractor · 1922Unverified

Eagle Manufacturing H 16-30

Name: Eagle Manufacturing H 16-30
Brand: Eagle Manufacturing

Eagle Manufacturing H 16-30 — Standard-tread tractor · 16 hp. Reference specifications; pending source verification.

The Eagle Manufacturing H 16-30 is a tractor with a rated power output of 16 hp, positioning it at the lower end of its class in terms of power. It was manufactured from 1922 to 1930. The tractor features a 2-cylinder liquid-cooled engine, paired with two-wheel drive and a 2-speed gearbox. Its operating weight is 3220 kg.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

16 hp

Weight

3220 kg

Catalogue coverage

Variants represented

Richest spec table

33 rows

Recorded power

16 hp

Recorded weight

3220 kg

Transmissions

2-speed gear

Production years

1922-1930

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerEagle ManufacturingReference

Standard-tread tractorReference

Built in Appleton, Wisconsin, USAReference

Two-wheel driveReference

Final drivesspur gearReference

Manual steeringReference

Open operator station.Reference

Engine

Eagle Manufacturing 13.2L 2-cyl keroseneReference

Drawbar (claimed)11.9 kWReference

Belt (claimed)22.4 kWReference

Plows4 (14-inch)Reference

Eagle ManufacturingReference

keroseneReference

2-cylinder 4-valveReference

liquid-cooledReference

Displacement13.2 LReference

Bore/Stroke203 x 203 mmReference

Fuel systemSchebler carburetorReference

Rated RPM450Reference

Starter typehand-crankReference

Transmission

2-speed gearReference

TypegearReference

Gears2 forward and 1 reverseReference

Dimensions

Weight3220 kgReference

Rear tire52x12Reference

Ag rear52x12 (steel)Reference

Length358 cmReference

Width177 cmReference

Height198 cmReference

Capacities

Diameter60 cmReference

Width25 cmReference

RPM450Reference

Speed853.44 meters/minReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
