Tractor · 1948Unverified
Earthmaster C
Earthmaster C — Utility tractor. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Weight
936 kg
Hover a source tag to verify
Overview
ManufacturerEarthmasterReference
Utility tractorReference
Built in Burbank, California, USAReference
Two-wheel driveReference
Disc brakesReference
Engine
Continental 1.0L 4-cyl gasolineReference
Fuel tank26.5 LReference
Plows1 (14-inch)Reference
Continental N62Reference
gasolineReference
4-cylinderReference
liquid-cooled vertical L-headReference
Displacement1.0 LReference
Bore/Stroke61 x 89 mmReference
Air cleanerVortox oil bathReference
Rated RPM2000Reference
Torque50.2 NmReference
Torque RPM1600Reference
Coolant capacity5.7 LReference
Oil capacity3.8 LReference
Transmission
3-speedReference
Gears3 forward and 1 reverseReference
Oil capacity2.4 LReference
Oil type[0oC]Reference
32oF [0oC]↑: SAE140Reference
32oF [0oC]↓: SAE90Reference
PTO & Hydraulics
Rear PTOtransmissionReference
Dimensions
Wheelbase167 cmReference
Weight936 kgReference
Front tire4.00x15Reference
Rear tire8x24Reference
Ag front4.00x15Reference
Ag rear8x24Reference
Ag rear9x24Reference
Length248 cmReference
Width129 cmReference
Height154 cmReference
Shipping weight936 kgReference
Ground clearance50 cmReference
Capacities
RPM1540Reference
Speed862.58 meters/minReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
