The Ebro 684E is a tractor model with a rated power of 82 hp, a mid-range figure for its class. It is powered by a 6-cylinder diesel liquid-cooled engine, paired with two-wheel drive with a 6-speed gearbox. It has a listed operating weight of 3079 kg, and it suits operations of up to 200 ac. Recorded specifications in UK and US units are listed below.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
82 hp
Weight
3079 kg
Catalogue coverage
Variants represented
2
Richest spec table
43 rows
Recorded power
82 hp
Recorded weight
3079 kg
Transmissions
6-speed gear
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerEbroReference
Built in SpainReference
Two-wheel driveReference
Power steeringReference
Wet disc brakesReference
Open operator station.Reference
Engine
Perkins 5.0L 6-cyl dieselReference
Engine61.1 kWReference
PerkinsReference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke91 x 127 mmReference
Power61.1 kWReference
Fuel system6.305Reference
Air cleanerdryReference
Rated RPM2100Reference
StarterelectricReference
Starter volts12Reference
Oil capacity11.6 LReference
Coolant capacity17.0 LReference
Transmission
6-speed gearReference
TypegearReference
Gears6 forward and 2 reverseReference
Clutch279mm dry discReference
Oil capacity14.0 LReference
Capacities
Fuel102.2 LReference
PTO & Hydraulics
Hydraulic system70.0 LReference
Capacity70.0 LReference
Rear TypeIIReference
Rear PTO Type540 (1.375)Reference
Engine RPM543@1950Reference
Dimensions
Weight3079 kgReference
Front tire7.50x16Reference
Rear tire15x30Reference
Ag front7.50x16Reference
Ag rear15x30Reference
Length344 cmReference
Height (steering wheel)168 cmReference
Ground clearance40 cmReference
Front tread135 to 175 cmReference
Rear tread151 to 182 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
