The Eicher 243 is a tractor rated at 24 hp — making it one of the more compact options in its class. Power comes from a 1-cylinder diesel air-cooled engine, driving through two-wheel drive with a 8-speed gearbox. Listed weight is 1764 kg, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
24 hp
Weight
1764 kg
Catalogue coverage
Variants represented
2
Richest spec table
31 rows
Recorded power
24 hp
Recorded weight
1764 kg
Transmissions
8-speed gear
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerEicherReference
Built in IndiaReference
Two-wheel driveReference
Manual steeringReference
Mechanical dry disc brakesReference
Open operator station.Reference
Engine
Eicher 1.6L 1-cyl dieselReference
Fuel tank45.0 LReference
Engine17.9 kWReference
Eicher 115 NCReference
dieselReference
1-cylinderReference
air-cooledReference
Displacement1.6 LReference
Bore/Stroke115 x 150 mmReference
Power17.9 kWReference
Fuel systemdirect injectionReference
Rated RPM1650Reference
Starter typeelectricReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch232mm mechanical dry discReference
PTO & Hydraulics
Rear PTOliveReference
Rear PTO Type1000Reference
Dimensions
Wheelbase188 cmReference
Weight1764 kgReference
Length325 cmReference
Width162 cmReference
Height203 cmReference
Ground clearance40 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
