Tractor · 1947Unverified
Empire 90
Empire 90 · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1134 kg
Hover a source tag to verify
Overview
ManufacturerEmpireReference
Built in Philadelphia, Pennsylvania, USAReference
Two-wheel driveReference
SteeringmanualReference
Open operator station.Reference
Engine
Willys 2.2L 4-cyl gasolineReference
Fuel tank26.9 LReference
Engine29.8 kWReference
WillysReference
gasolineReference
4-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke79 x 111 mmReference
Power29.8 kWReference
Air cleaneroil bathReference
Rated RPM2000Reference
Oil capacity3.8 LReference
Coolant capacity15.1 LReference
Transmission
6-speed gearReference
TransmissionWarner Gear T-90Reference
TypegearReference
Gears6 forward and 2 reverseReference
Clutchdry discReference
Three gears (1-3) plus reverse (R) with a two-speed Spicer transfer case.Reference
Dimensions
Wheelbase194 cmReference
Weight1134 kgReference
Front tire5.50-16Reference
Rear tire9-24Reference
Ag front5.50-16Reference
Ag rear9-24Reference
90 Serial Number Location
On dashboard behind steering wheel.Reference
Electrical
Charging systemAutolight generatorReference
Charging amps35Reference
Charging volts6Reference
Battery volts6Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
