Tractor · 2010Unverified
Erkunt Kudret 105E
Erkunt Kudret 105E — Row-Crop tractor · 100 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
100 hp
Weight
8788 to 8973 pounds
Hover a source tag to verify
Overview
ManufacturerErkuntReference
Row-Crop tractorReference
Built in Ankara, TurkeyReference
Four-wheel driveReference
Four-post ROPS. Cab optional.Reference
Engine
Perkins 4.4L 4-cyl dieselReference
Fuel tank110.1 LReference
Engine74.9 kWReference
Perkins 1104D-44TReference
turbocharged intercooled dieselReference
4-cylinderReference
liquid-cooledReference
Displacement4.4 LReference
Bore/Stroke105 x 127 mmReference
EmissionsStage IIIAReference
Power74.9 kWReference
Rated RPM2200Reference
Torque405.0 NmReference
Torque RPM1400Reference
Starter typeelectricReference
Transmission
12-speed sync shuttleReference
24-speed sync shuttleReference
Typesync shuttleReference
Gears12 forward and reverseReference
Gears24 forward and reverseReference
PTO & Hydraulics
Pressure190.0 barReference
Valves4Reference
Pump flow48.4 lpmReference
Rear lift3400 kgReference
Rear PTOindependentReference
Rear PTO Type540/540EReference
Dimensions
Wheelbase232 cmReference
Weight8788 to 8973 poundsReference
Front tire320/85R24Reference
Rear tire460/85R30Reference
Standard tires (ag)Front: 320/85R24. Rear: 460/85R30Reference
Standard tires (ag)Front: 320/85R28. Rear: 380/85R38Reference
Length411 cmReference
Width199 cmReference
Height (cab)272 cmReference
ROPS Weight3986 kgReference
Cab Weight4070 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
