Tractor · 1957Unverified

Fahr D130A

Name: Fahr D130A
Brand: Fahr

Fahr D130A · 17 hp. Reference specifications; pending source verification.

The Fahr D130A tractor model is rated at approximately 17 hp, positioning it among the lighter models in its class. Production of the D130A took place from 1957 to 1958. It features a 2-cylinder diesel air-cooled engine, paired with two-wheel drive and a 10-speed gearbox. The operating weight of the Fahr D130A is listed as 1140 kg, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

17 hp

Weight

1140 kg

Catalogue coverage

Variants represented

Richest spec table

27 rows

Recorded power

17 hp

Recorded weight

1140 kg

Transmissions

10-speed gear

Production years

1957-1958

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFahrReference

Total built1244Reference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

D130AstandardReference

D130AHhigh-wheelReference

Engine

Guldner 1.3L 2-cyl dieselReference

Engine12.7 kWReference

Guldner 2LDReference

dieselReference

2-cylinderReference

air-cooledReference

Displacement1.3 LReference

Bore/Stroke85 x 115 mmReference

Power12.7 kWReference

Transmission

10-speed gearReference

TransmissionFahr F5AReference

TypegearReference

Gears10 forward and 2 reverseReference

PTO & Hydraulics

Rear PTO Type540Reference

Dimensions

Wheelbase166 cmReference

Wheelbase173 cmReference

Weight1140 kgReference

Length272 cmReference

Width146 cmReference

Height172 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
