Tractor · 1951Unverified
Fahr D17
Fahr D17 · 17 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
17 hp
Weight
1231 kg
Hover a source tag to verify
Overview
ManufacturerFahrReference
Total built5658Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
D17regular wheelReference
D17Hhigh-wheelReference
Engine
Guldner 1.3L 2-cyl dieselReference
Engine12.7 kWReference
Guldner 2D15Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke85 x 115 mmReference
Power12.7 kWReference
Transmission
5-speed gearReference
TransmissionZF A8CReference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase164 cmReference
Weight1231 kgReference
Length257 cmReference
Width156 cmReference
Height174 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
