Tractor · 1958Unverified
Fahr D177
Fahr D177 · 34 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
34 hp
Weight
1655 kg
Hover a source tag to verify
Overview
ManufacturerFahrReference
Total built1743Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Daimler-Benz 1.8L 4-cyl dieselReference
Engine25.4 kWReference
Daimler-Benz OM636Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke75 x 100 mmReference
Power25.4 kWReference
Transmission
8-speed gearReference
TransmissionZF A208Reference
TypegearReference
Gears8 forward and 4 reverseReference
PTO & Hydraulics
Rear PTO Type540/1000Reference
Dimensions
Wheelbase195 cmReference
Weight1655 kgReference
Length320 cmReference
Width155 cmReference
Height154 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
