Tractor · 1951Unverified
Fahr D25
Fahr D25 · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1837 kg
Hover a source tag to verify
Overview
ManufacturerFahrReference
Total built1748Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
D25regularReference
D25Hhigh-wheelReference
Engine
Deutz 2.2L 2-cyl dieselReference
Engine18.6 kWReference
Deutz F2M414Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke100 x 140 mmReference
Power18.6 kWReference
Rated RPM1550Reference
Transmission
5-speed gearReference
TransmissionZF A15Reference
TypegearReference
Gears5 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase178 cmReference
Weight1837 kgReference
Length286 cmReference
Width153 cmReference
Height182 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
