Tractor · 1951Unverified

Fahr D25

Name: Fahr D25
Brand: Fahr

Fahr D25 · 25 hp. Reference specifications; pending source verification.

The Fahr D25 is a tractor with a power rating of approximately 25 hp, positioning it at the lower end of its class in terms of power output. It was manufactured from 1951 to 1953. The tractor is equipped with a 2-cylinder diesel liquid-cooled engine and a 5-speed gearbox with two-wheel drive. Its operating weight is listed at 1837 kg, making it suitable for operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

25 hp

Weight

1837 kg

Catalogue coverage

Variants represented

Richest spec table

27 rows

Recorded power

25 hp

Recorded weight

1837 kg

Transmissions

5-speed gear

Production years

1951-1953

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerFahrReference

Total built1748Reference

Two-wheel driveReference

Manual steeringReference

Open operator station.Reference

Variants

D25regularReference

D25Hhigh-wheelReference

Engine

Deutz 2.2L 2-cyl dieselReference

Engine18.6 kWReference

Deutz F2M414Reference

dieselReference

2-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke100 x 140 mmReference

Power18.6 kWReference

Rated RPM1550Reference

Transmission

5-speed gearReference

TransmissionZF A15Reference

TypegearReference

Gears5 forward and 1 reverseReference

PTO & Hydraulics

Rear PTO Type540Reference

Dimensions

Wheelbase178 cmReference

Weight1837 kgReference

Length286 cmReference

Width153 cmReference

Height182 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
