The Fahr D25H is a compact tractor model with a 25 hp rating, making it one of the smaller options in its class. It was produced between 1951 and 1953. The tractor features a 2-cylinder diesel liquid-cooled engine, driving through two-wheel drive via a 6-speed gearbox. The listed weight is 1882 kg, and it is suitable for use on land areas of up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
1882 kg
Catalogue coverage
Variants represented
2
Richest spec table
27 rows
Recorded power
25 hp
Recorded weight
1882 kg
Transmissions
6-speed gear
Production years
1951-1953
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFahrReference
Total built543Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Variants
D25regularReference
D25Hhigh-wheelReference
Engine
Deutz 2.2L 2-cyl dieselReference
Engine18.6 kWReference
Deutz F2M414Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke100 x 140 mmReference
Power18.6 kWReference
Rated RPM1550Reference
Transmission
6-speed gearReference
TransmissionFahr F12Reference
TypegearReference
Gears6 forward and 1 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase183 cmReference
Weight1882 kgReference
Length291 cmReference
Width158 cmReference
Height181 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
