Tractor · 1952Unverified
Fahr D55L
Fahr D55L · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
3402 kg
Hover a source tag to verify
Overview
ManufacturerFahrReference
Total built5Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Deutz 5.3L 4-cyl dieselReference
Engine41.0 kWReference
Deutz F4L514Reference
dieselReference
4-cylinderReference
air-cooledReference
Displacement5.3 LReference
Bore/Stroke110 x 140 mmReference
Power41.0 kWReference
Transmission
8-speed gearReference
TransmissionZF A25Reference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Rear PTO Type540Reference
Dimensions
Wheelbase223 cmReference
Weight3402 kgReference
Length383 cmReference
Width186 cmReference
Height154 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
