The Fahr F22 is a compact tractor with a power output of 22 hp. Manufactured between 1938 and 1941, it features a 2-cylinder diesel liquid-cooled engine, driving through a two-wheel drive system with a 5-speed gearbox. The tractor weighs approximately 1800 kg and is suited for tasks involving up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
22 hp
Weight
1800 kg
Catalogue coverage
Variants represented
2
Richest spec table
25 rows
Recorded power
22 hp
Recorded weight
1800 kg
Transmissions
5-speed gear
Production years
1938-1941
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerFahrReference
Total built450Reference
Two-wheel driveReference
Manual steeringReference
Open operator station.Reference
Engine
Deutz 2.2L 2-cyl dieselReference
Engine16.4 kWReference
Deutz F2M414Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement2.2 LReference
Bore/Stroke100 x 140 mmReference
Power16.4 kWReference
Rated RPM1500Reference
Transmission
5-speed gearReference
TransmissionFahrReference
TypegearReference
Gears5 forward and 1 reverseReference
Dimensions
Wheelbase169 cmReference
Weight1800 kgReference
Length279 cmReference
Width153 cmReference
Height150 cmReference
Ground clearance28 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
