Tractor · 2002Unverified
Farm Pro 2420
Farm Pro 2420 — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1206 kg
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Compact Utility tractorReference
Built in ChinaReference
Two-wheel driveReference
Steeringpower optionalReference
ROPS canopyReference
Engine
1.2L 2-cyl dieselReference
Engine14.9 kWReference
TY290Reference
dieselReference
2-cylinderReference
liquid-cooledReference
Displacement1.2 LReference
Bore/Stroke90 x 100 mmReference
Power14.9 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.0 LReference
Coolant capacity10.0 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Oil capacity11.0 LReference
Capacities
Fuel20.8 LReference
PTO & Hydraulics
Hydraulic system9.1 LReference
Capacity9.1 LReference
Total flow11.4 lpmReference
Rear TypeIReference
Rear PTOliveReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase152 cmReference
Weight1206 kgReference
Front tire4.00-16Reference
Rear tire8.3-24Reference
Ag front4.00-16Reference
Ag rear8.3-24Reference
Length290 cmReference
Width142 cmReference
Height218 cmReference
Shipping weight1206 kgReference
Ground clearance25 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
