Tractor · 2005Unverified
Farm Pro 2510
Farm Pro 2510 — Jinma built · 25 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2248 to 2513 pounds
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
ROPS canopyReference
Engine
1.5L 3-cyl dieselReference
Engine18.6 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke85 x 90 mmReference
Power18.6 kWReference
Rated RPM2350Reference
Oil capacity6.0 LReference
Coolant capacity7.9 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Oil capacity14.0 LReference
Capacities
Fuel18.2 LReference
PTO & Hydraulics
Hydraulic system9.0 LReference
Capacity9.0 LReference
Pressure137.9 barReference
Total flow18.2 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)396 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase164 cmReference
Weight2248 to 2513 poundsReference
Front tire6.00-16Reference
Rear tire9.5-24Reference
Ag front6.00-16Reference
Ag rear9.5-24Reference
Length299 cmReference
Width129 cmReference
Height143 cmReference
Shipping weight1019 kgReference
Operating weight1139 kgReference
Ground clearance29 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
