Tractor · 2005Unverified
Farm Pro 2510
Farm Pro 2510 — Jinma built · 25 hp. Reference specifications; pending source verification.
The Farm Pro 2510 is a tractor model with a rated power of 25 hp, situating it at the lighter end of its class. It was manufactured from 2005 to 2012 and features a 3-cylinder diesel liquid-cooled engine, coupled with four-wheel drive and a 12-speed gearbox. The operating weight of the 2510 ranges from 2248 to 2513 pounds. It is suitable for operations covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
25 hp
Weight
2248 to 2513 pounds
Catalogue coverage
Variants represented
2
Richest spec table
41 rows
Recorded power
25 hp
Recorded weight
1019 kg
Transmissions
12-speed
Production years
2005-2012
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
DistributorFarm ProReference
ManufacturerJinmaReference
Built in ChinaReference
Four-wheel driveReference
SteeringpowerReference
ROPS canopyReference
Engine
1.5L 3-cyl dieselReference
Engine18.6 kWReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke85 x 90 mmReference
Power18.6 kWReference
Rated RPM2350Reference
Oil capacity6.0 LReference
Coolant capacity7.9 LReference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
Oil capacity14.0 LReference
Capacities
Fuel18.2 LReference
PTO & Hydraulics
Hydraulic system9.0 LReference
Capacity9.0 LReference
Pressure137.9 barReference
Total flow18.2 lpmReference
Rear TypeIReference
Rear lift (at 24"/610mm)396 kgReference
Rear PTOlive (2-stage clutch)Reference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase164 cmReference
Weight2248 to 2513 poundsReference
Front tire6.00-16Reference
Rear tire9.5-24Reference
Ag front6.00-16Reference
Ag rear9.5-24Reference
Length299 cmReference
Width129 cmReference
Height143 cmReference
Shipping weight1019 kgReference
Operating weight1139 kgReference
Ground clearance29 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
